Fritted Ware
Quartz fritted ware combines porous quartz elements with discs, plates, rods, filters, funnels and bubbler assemblies. Select a product family below, then specify the frit form, filtration or diffusion purpose, dimensions, connections and quantity.
Quartz Fritted Products
Porous Quartz Components and Assemblies
Fritted elements can be supplied as individual parts or integrated into laboratory and process assemblies. Selection depends on the required gas or liquid flow, retention function, chemical and thermal conditions, and the geometry used to mount or seal the frit.
What to Specify
Provide the frit shape and dimensions, intended filtration or diffusion function, mating tube or vessel dimensions, joints or connections, operating media, temperature conditions and quantity. Samples or drawings help match replacement parts.
Typical Applications
Fritted quartz products are used for filtration, gas dispersion, liquid distribution, catalyst support, vacuum and laboratory processing, and custom high-temperature flow systems.
FAQ
Provide dimensions, material, tolerances, processing, quantity and application conditions.
Yes. Cutting, grinding, drilling, polishing, hot forming and welding can be reviewed against the requested geometry.
Customize This Product
Enter your dimensions of Fritted Ware — the technical drawing updates instantly, then request a quotation.
Technical Drawing
Drawing redraws live · blue hatched area = cut section · all dimensions in mm
Parameters
Every field is editable — drawing, weight estimate and part code update instantly.
Common Options
pcs
Configuration Summary
Attached to your inquiry automatically when you press “Use This Configuration”.
—
