Custom Quartz Graduated Cylinders & Measuring Cups

Parameter	Typical Range
Capacity	10–1,000 mL
Main diameter	15–80 mm
Height	100–350 mm
Graduation interval	Scaled to capacity (e.g. 1 mL on a 10 mL cylinder, 10 mL on a 100 mL cylinder)
Base	Round foot or flat stable base

Inquiry

Custom Quartz Graduated Cylinders & Measuring Cups

Quartz measuring vessels sized by capacity and graduation range — where scale accuracy matters as much as the vessel itself.

Capacity and graduation interval move together — a finer interval than the vessel's diameter can readably support doesn't add real precision, it just adds marks that are hard to read accurately.

Graduation Range, Scale Marking and Readability

Graduations are frosted lines or printed marks, positioned and spaced for the target capacity. Readability depends on line width relative to vessel diameter — a narrow cylinder with fine graduations reads more precisely than a wide one with the same interval, since the fluid meniscus is easier to align on a narrower column.

Quartz Graduated Cylinders & Measuring Cups Size / Capacity / Joint Standard

Send target capacity and required graduation interval together, not just total volume — the interval determines how the graduations are laid out along the height, which in turn affects how tall or narrow the vessel needs to be. Fabrication is hot-formed from tube stock, with a stable base added and the rim fire-polished; graduations are added as a separate marking step. Before shipment we check capacity, graduation position/spacing, base stability, and appearance.

10–1000 mLCapacity Series

7Reference Capacities

Class AAccuracy Option

Class BAccuracy Option

±0.5–5 mLClass-A Reference Span

JGS2Material Option

Measurement Definition

Capacity, Graduation Interval and Accuracy Class Must Be Stated Together

Controlled Feature	Reference Capability / Requirement
Capacity	10, 25, 50, 100, 250, 500 or 1000 mL reference series
Vessel Form	Graduated cylinder or measuring cup
Graduation Interval	Selected from capacity and required readability
Accuracy Class	Class A or Class B requested explicitly
Accuracy Reference	Class-A span of approximately ±0.5–5 mL across the listed sizes; final value confirmed per capacity
Marking	Fired, etched or otherwise specified scale and label
Base / Spout	Stable base for cylinders; pouring rim for cups
Material	Transparent JGS2-class fused quartz option

Capacity and Accuracy

Quote the Accuracy at the Nominal Capacity

Capacity Group	Nominal Sizes	Quote Inputs
Small	10 / 25 / 50 mL	Class, interval and marking method
Medium	100 / 250 mL	Class, interval and base or spout
Large	500 / 1000 mL	Accuracy value and support geometry
Custom	By drawing	Calibration method and temperature reference
